Fujifilm X-T4 Full Specs Leaked

Share

Now nokishita leaked the full specs for the Fujifilm X-T4.

Some new stuff, but mostly we know everything already from previous Fujifilm X-T4 leaks here on FujiRumors.

Most interesting: the EVF is the same and battery life in economy mode goes up to 600 shots, in normal mode up to 500.

Join FujiRumors on PatreonFacebook, Instagram, RSS-feed, Youtube, Flipboard and Twitter
Top X-T Community: Fujifilm X-T facebook group
Top X-T Page: Fujifilm X-T Page

Fujifilm X-T4 Full Specs List

Number of effective pixels 26.1 millions pixels

Image sensor
23.5mm x15.6mm (APS-C) X-Trans CMOS 4 with primary color filter.

Sensor Cleaning system Ultra Sonic Vibration

Storage media
SD memory card (-2GB) / SDHC memory card (-32GB) / SDXC memory card (-512GB) UHS-I / UHS-II / Video Speed Class V90

File Format
Still image JPEG: Exif Ver.2.3, RAW: 14bit RAW (RAF original format) TIFF: 8/16bit RGB

Number of Recorded Pixels
L: (3:2) 6240 x 4160 / (16:9) 6240 x 3512/ (1:1) 4160 x 4160 M: (3:2) 4416 x 2944/ (16:9) 4416 x 2488/ (1:1) 2944 x 2944 S: (3:2) 3120 x 2080 / (16:9) 3120 x 1760 / (1:1) 2080 x 2080

Movie
MOV (MPEG-4 AVC/H.264, HEVC/H.265, Audio: Linear PCM / Stereo sound 24bit / 48KHz sampling), MP4 (MPEG-4 AVC/H.264, Audio: AAC)

Sensitivity
Standard output sensitivity: AUTO1 / AUTO2 / AUTO3 (up to ISO12800) / ISO160-12800 (1/3 step)
Extended output sensitivity: ISO80/100/125/25600/51200

Exposure control
TTL 256-zone metering, Multi / Spot / Average / Center Weighted

Exposure Modes
P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure)

Exposure compensation
-5.0EV – +5.0EV 1/3EV step

Movie recording
-2.0EV – +2.0EV

Image Stabilizer Mechanism
Image sensor shift mechanism with 5-axis compensation

Image Stabilizer Compensation Effect
Maximum 6.5 stops (based on CIPA standard. Pitch/yaw shake only. With XF35mmF1.4 R lens mounted.)

Digital Image Stabilizer
Yes (movie mode only)

IS Mode Boost
Yes (movie mode only)

Face / Eye detection AF
Yes

Shutter type
Focal Plane Shutter

Mechanical Shutter
P mode: 4sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb mode: up to 60min.

Electronic Shutter
P mode: 4sec. to 1/32000sec. A mode: 30sec. to 1/32000sec. S/M mode: 15min. to 1/32000sec. Bulb mode: 1sec. Fixed

Electronic Front Curtain Shutter
P mode: 4sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb mode: up to 60min.

Mechanical + Electronic Shutter
P mode: 4sec. to 1/32000sec. A mode: 30sec. to 1/32000sec. S/M mode: 15min. to 1/32000sec. Bulb mode: up to 60min.

E-Front + Mechanical Shutter
P mode: 4sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb mode: up to 60min
Electronic front curtain shutter works until 1/2000sec.

E-Front + Mechanical + Elec. Shutter
P mode: 4sec. to 1/32000sec. A mode: 30sec. to 1/32000sec. S/M mode: 15min. to 1/32000sec. Bulb mode: up to 60min.
Electronic front curtain shutter works until 1/2000sec, Mechanical shutter works until 1/8000sec.

Movie Shutter
FHD: 1/8000sec. to 1/4sec.
DCI4K/4K: 1/8000sec. to 1/24sec. (depends on the frame rate)

Synchronized shutter speed for flash
1/250sec. or slower

Continous Shooting
Approx. 30fps [Only electronic shutter, 1.25 x Crop ] (JPEG: 60 frames Lossless compressed RAW / Compressed RAW: 35 frames Uncompressed RAW: 33 frames)
Approx. 20fps [Only electronic shutter, 1.25 x Crop ] (JPEG: 114 frames Lossless compressed RAW / Compressed RAW: 37 frames Uncompressed RAW: 34 frames)
Approx. 10fps [Only electronic shutter, 1.25 x Crop ] (JPEG: 500 frames Lossless compressed RAW / Compressed RAW: 48 frames Uncompressed RAW: 39 frames)

Approx. 20fps [Only electronic shutter ] (JPEG: 79 frames Lossless compressed RAW / Compressed RAW: 36 frames Uncompressed RAW: 34 frames)
Approx. 15fps (JPEG: 110 frames Lossless compressed RAW / Compressed RAW: 38 frames Uncompressed RAW: 35 frames)

Approx. 10fps (JPEG: 164 frames Lossless compressed RAW / Compressed RAW: 44 frames Uncompressed RAW: 37 frames)
Approx. 8fps (JPEG: 200 frames Lossless compressed RAW / Compressed RAW: 49 frames Uncompressed RAW: 39 frames)

Pre-shot
Approx. 30fps [Only electronic shutter, 1.25 x Crop ] (max. 20 frames while half press, max. 20 frames after full press, total max. 40 frames) Pre-shot: Approx. 20fps [Only electronic shutter, 1.25 x Crop ] (max. 20 frames while half press, max. 37 frames after full press, total max. 57 frames) Pre-shot: Approx. 10fps [Only electronic shutter, 1.25 x Crop ] (max. 10 frames while half press, max. 300 frames after full press, total max. 310 frames)

Auto Bracketing
AE Bracketing (Frames: 2, 3, 5, 7, 9 Step: by 1/3EV step, up to +/-3EV steps) Filmsimulation bracketing (Any 3 types of film simulation selectable)
Dynamic Range Bracketing (100%, 200%, 400%)
ISO sensitivity Bracketing ( +/-1/3EV, +/-2/3EV, +/-1EV)
White Balance Bracketing ( +/-1, +/-2, +/-3)
Focus Bracketing (AUTO, MANUAL)

Focus Mode
Single AF / Continuous AF / MF

Focus Type
Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)

Focu Low-Light Performance
Contrast: -3.0EV Phase Detection: -6.0EV (XF35mmF1.4 attached)

Focus AF Frame Selection
Single point AF: EVF / LCD: 13×9 / 25×17 (Changeable size of AF frame) Zone AF: 3×3 / 5×5 / 7×7 from 91 areas on 13×9 grid
Wide/Tracking AF, AF-S: Wide / AF-C: Tracking All

White Balance
Auto (WHITE PRIORITY, AUTO, AMBIENCE PRIORITY), / Custom1-3 / Color temperature selection (2500K-10000K) / Preset: Fine, Shade, Fluorescent light (Daylight), Fluorescent light (Warm White), Fluorescent light (Cool White), Incandescent light, Underwater

Self-timer
10sec. / 2sec.

Interval Timer Shooting
Yes (Setting: Interval, Number of shots, Starting time)

Flash Sync Mode
1ST CURTAIN / 2ND CURTAIN / AUTO FP(HSS) (excl. EF-X8)

Flash Mode
TTL (TTL AUTO (P mode) / STANDARD / SLOW SYNC. ) / MANUAL / COMMANDER / OFF (When EF-X8 is set)
TTL (TTL AUTO (P mode) / STANDARD / SLOW SYNC. ) / MANUAL / MULTI / OFF (When SHOE MOUNT FLASH is set)

Hot Shoe
Yes (Dedicated TTL Flash compatible)

Viewfinder
0.5 inch approx. 3.69 millions dots OLED Color Viewfinder
Coverage of viewing area vs. capturing area: approx. 100%
Eyepoint: approx. 23mm (from the eyepiece lens)
Diopter adjustment: -4-+2m-1 (lockable)
Magnification: 0.75 x with 50mm lens (35mm equivalent) at infinity and diopter set to -1m-1
Diagonal angle of view: approx. 38 Degree (Horizontal angle of view: approx. 30 Degree )
Built-in eye sensor

LCD monitor
3.0 inch, aspect ratio 3:2, approx. 1.62 millions dots touch screen color LCD monitor (approx. 100% coverage)

Movie Recording File Format
MOV (MPEG-4 AVC/H.264, HEVC/H.265, Audio: Linear PCM / Stereo sound 24bit / 48KHz sampling)
MP4 (MPEG-4 AVC/H.264, Audio: AAC)

Movie Recording Compression
All Intra/Long-GOP

DCI4K/4K 29.97p/25p/24p/23.98p 400Mbps Full HD (2048 x1080)/ Full HD (1920×1080) 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps

Movie File Size/Frame Rate/Rec. Time
[DCI 4K (4096 x2160)]59.94p/50p/29.97p/25p/24p/23.98p 400Mbps/200Mbps/100Mbps 59.94p/50p: up to approx. 20min. 29.97p/25p/24p/23.98p: up to approx. 30min

[4K (3840×2160)]59.94p/50p/29.97p/25p/24p/23.98p 400Mbps/200Mbps/100Mbps 59.94p/50p: up to approx. 20min. 29.97p/25p/24p/23.98p: up to approx. 30min

[Full HD (2048 x1080)] 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps/100Mbps/50Mbps up to approx. 30min.

[Full HD (1920 x1080)] 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps/100Mbps/50Mbps up to approx. 30min.

[Full HD (1920 x1080) High speed rec.] 240p / 200p 200Mbps(recording) up to approx. 3min. 120p / 100p 200Mbps(recording) up to approx. 6min.

Film Simulation mode
18 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Black & White, Black & White+Ye Filter, Black & White+R Filter, Black & White+G Filter, Sepia, ACROS, ACROS+Ye Filter, ACROS+R Filter, ACROS+G Filter, ETERNA/Cinema, Classic Neg, ETERNA BLEACH BYPASS) Monochromatic Color

Clarity Setting
+/-5 steps

HDR Mode
AUTO, 200%, 400%, 800%, 800% +

Grain Effect
Roughness: STRONG, WEAK, OFF Size: LARGE, SMALL

Color Chrome Effect STRONG, WEAK, OFF

Color Chrom Effect Blue STRONG, WEAK, OFF

Dynamic Range Setting Still
AUTO, 100%, 200%, 400%
ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more)

Dynamic Range Setting Movie
100%, 200%, 400%
ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more)

Advanced Filter
Toy camera, Miniature, Pop color, High-key, Low-key, Dynamic tone, Soft focus, Partial color (Red / Orange / Yellow / Green / Blue / Purple)

Wireless Transmitter Standard
IEEE802.11b/g/n (standard wireless protocol)

Wireless Transmitter Encryption
WEP / WPA / WPA2 mixed mode

Wireless Encryption Access mode Infrastructure

Bluetooth Standard
Bluetooth Ver 4.2 (Bluetooth low energy)

Bluetooth Operating frequency
2402 – 2480MHz (Center frequency)

Terminal

Digital interface: USB Type-C (USB3.2 Gen1x1)
HDMI output: HDMI micro connector (Type D)
Other: 3.5mm, stereo mini connector (Microphone) / 2.5mm, Remote Release Connector, Hot shoe, Synchronized terminal

Power supply
NP-W235 Li-ion battery (included)

Battery life for still images
Approx. 600 frames (Economy Mode), approx. 500 frames (Normal Mode) When XF35mmF1.4 R is set.

Actual battery life of movie capture Face detection is set to OFF
[4K] approx. 85min. (29.97p) [Full HD] approx. 95min. (59.94p)

Continuance battery life
Face detection is set to OFF
[4K] approx. 110min. (29.97p)
[Full HD] approx. 130min. (59.94p) (movie capture)

Operating Temerature
-10 Degree C-+40 Degree C

Operating Humidity
10%-80% (no condensation)

Battery
Li-ion battery NP-W235

Starting up period Approx. 0.39sec.

Dimensions (D x W x H)
63.8 x 134.6 x 92.8 mm

Weight
Approx. 607g (including battery and SD memory card) Approx. 526g (excluding battery and SD memory card)

via nokishita
